NX500 2024

  • RRP:
    £6,799.00OTR

NX500 2024 Promotions


Model Specification


Model Description


New Experience

Where to? Your choice. The compact, versatile new NX500 offers perfect city agility and off-road ability. It’s comfortable too, with an aggressive, rally-style fairing and large screen shaped for wind protection. High specification technology includes 5-inch TFT screen with Honda RoadSync smartphone connectivity. And its A2-compliant twin-cylinder engine delivers flexible – hugely enjoyable – performance with HSTC traction management. The adventure begins.

Go Short. Go long.

Go where you choose. Effortlessly at home in the city but built for adventure, the rugged NX500 blends a tough off-road silhouette with modern off-road-inspired design. Long-travel suspension absorbs the urban rough and tumble just as it does gravel trails helped by new, lightweight wheels. The 17.7L fuel tank holds plenty of range. And a relaxed riding position – and natural control of wide handlebars – are matched to an aerodynamic package that neatly channels airflow.

Make The Connection

This bike’s got your back. The 5-inch full-colour TFT display is all new, operated by a backlit switchgear with a very natural hand position allowing better visibility in all conditions. Both have been designed together for easy use, and the screen is engineered to minimise glare in bright sunlight. It also offers full connectivity through the Honda RoadSync app. A first in class, for Android and iOS smartphones, it means you can access on-screen turn-by-turn navigation, make and receive calls or listen to music while you ride.

Model Specification


  • Engine

    Engine Type

    Liquid-cooled 4-stroke DOHC parallel twin

    Engine Displacement

    471cc

    Bore and Stroke

    67mm x 66.8mm

    Carburation

    PGM-FI electronic fuel injection

    Compression Ratio

    10.7:1

    Ignition

    Starter

    Electric

    Oil Capacity

    3.2L

  • Performance

    Max Torque

    43Nm/6,500rpm

    Max Power

    35kW [47hp] / 8,600rpm

  • Dimensions

    Length x Width x Height

    Wheelbase

    1,445mm

    Ground Clearance

    180mm

    Seat Height

    830mm

    Fuel Capacity

    Tyres Front

    110/80R19M/C (59H)

    Tyres Rear

    160/60R17M/C (69H)

    Brakes Front

    Dual 296mm x 4mm disc with Nissin axial mounted two piston calipers

    Brakes Rear

    Dual 296mm x 4mm disc with Nissin axial mounted two piston calipers

    Dimensions

    Kerb Weight

    196kg

    Dry Weight

  • Wheels

    Suspension Front

    Showa 41mm SFF-BP USD forks

    Suspension Rear

    Prolink mono with 5 stage pre-load adjuster, Steel hollow cross swingarm

    Wheels Front

    19M/C X MT2.5 Multi-Spoke Cast Aluminium

    Wheels Rear

    160/60R17M/C (69H)

  • Transmission

    Transmission

    Gearbox

    6-speed

    Final Drive

    Chain

    Transmission Type

  • Frame

    Frame Type

    Steel diamond
